제품 상세 정보:
|
| 전압: | 380V 50Hz 3 상 | 상태: | 새로운 |
|---|---|---|---|
| 보증: | 2년 | 유형: | 철골 & 중도리 기계 |
| 판매 후 서비스 제공: | 해외에서 기계를 서비스할 수 있는 엔지니어 | 이름: | 중도리 롤 성형기 |
| 강조하다: | galvanized steel roll forming machine,custom sized profile forming machine,purlin roll forming machine with warranty |
||
| Component | Specifications |
|---|---|
| Material of Coil | Material Thickness: 2.5-3mm |
| Main Frame | Material: 400H-beam Steel |
| Wall Plate | Welded Steel Plate |
| Reducer | 8# Cycloid Reducer |
| De-coiler | Weight: 3 ton manual decoiler |
| Roll Forming System | Rolling Speed: 0-12 m/min |
| Roller Stations | About 14 stations forming |
| Roller Material | GCR15 Steel with Hard Chromium Plated Surface |
| Diameter of Shaft | 80 Solid |
| Shaft Material | 45# Steel Diameter 80mm Shaft |
| Main Motor Power | 15 kW |
| Hydraulic Cutting Power | 5.5 kW |
| Cutting | Material: CR12 with Quench Treatment |
| Tolerance | ±1mm |
| Cutting Blade | Hydraulic Shearing |
| Electrical Control System | Electric Source: 380V, 50Hz, 3 Phase Control System: PLC (Delta) with Touch Screen |
| Weight | About 6 Tons |
| Way of Drive | By Chain (2.0 inch) Link Bearing Model 6210 |
| Size of Machine | 8.2m × 1.2m × 1.2m |
